16.3 System resources
SIMATIC Box PC 627
Operating Instructions, Release 05/2006, A5E00362052-03
16-21
16.3 16.3 System resources
16.3.1 Currently allocated system resources
All system resources (hardware address, memory configuration, IRQ, DMA channel) are
assigned dynamically by the Windows OS, depending on the hardware configuration, drivers
and connected peripheral devices. You can view the current configuration of system
resources or possible conflicts with the following operating systems:
Windows 2000/XP Start > Run : in the Run dialog, enter msinfo32 and confirm with OK.
16.3.2 System resources used by the BIOS/DOS
The following table describes the system resources for the factory state of the device.
16.3.2.1 I/O address allocation
I/O address
(hex)
Description of the basic function Possible alternative
function
from to
0000 0CF7 DMA controller
0020 0021 Programmable interrupt controller
0024 0025 Programmable interrupt controller
0028 0029 Programmable interrupt controller
002C 002D Programmable interrupt controller
002E 002F Basic unit resources
0030 0031 Programmable interrupt controller
0034 0035 Programmable interrupt controller
0038 0039 Programmable interrupt controller
003C 003D Programmable interrupt controller
0040 0043 System timer
004E 004F Basic unit resources
0050 0053 System timer
0060 0060 Keyboard controller
0061 0061 Basic unit resources
0063 0063 Basic unit resources
0064 0064 Keyboard controller
0065 0065 Basic unit resources
0067 0067 Basic unit resources
0070 0070 Basic unit resources
0070 0070 System CMOS/real-time clock
0080 0080 Basic unit resources
0081 0091 DMA controller
