Technical Data
14.1 General Specifications
SIMATIC Box PC 627
Operating Instructions, Release 05/2006, A5E00362052-03
14-3
General technical data
Disk drives
Hard disk 3.5" / 2.5" Serial ATA, See order documentation for hard
disk capacity
- 1.5 Gbit/s data transmission rate
- supports NCQ (Native Command Queuing;
SATA II property)
CD-ROM, DVD-ROM/CD-RW
∗2
ATA 33, See order documentation for features
Graphic
Graphic controller Intel
Graphic memory Graphics memory 8 to 132 MB SDRAM, some using
dynamic sharing of system RAM
Resolutions/frequencies/colors VGA: 1600x1200 / 32-bit color depth / 85 Hz
DVI-I: 1600 x 1200 / 32-bit color depth / 60 Hz
LCD: 1280 x 1024 / 18-bit
Interfaces
DVI Port for external CRT / LCD monitor
USB External: 4x USB 2.0 on the port side
(max. 2 can be simultaneously operated as high current)
Internal: 2x USB 2.0 (1x high current, 1x low current)
Front panel ports: 1x USB 2.0 high current
1x USB 1.1 high current
PROFIBUS / MPI interface
∗4
- Transmission speed
- Operating mode
- Physical interface
- Memory address space
- Interrupts
9-pin Cannon socket
9.6 Kbps to 12 Mbps, software-selectable
potential isolation:
- Data lines A,B
- Control lines RTS AS, RTS_PG
- 5V supply voltage (max. 90 mA)
Ground connection:
- DP12 connector cable shield
RS485, potential isolated *
5
Automatically configured
Automatically configured
Ethernet 2x Ethernet port (RJ45), 10/100 Mbit, VIA MAC. VT6106S
COM1 Serial port 1
9-pin Cannon socket
Compact Flash Slot for Compact Flash Card
Status displays on the device
DVD/CD access (to CD drive if installed)
Status LED for post codes (below the
7 segment displays)
*1
Restrictions for DVD-ROM/CD-RW: Burner operation only allowed under
ambient conditions +5° C to +40°C
*2
Restriction for DVD-ROM and DVD-ROM/CD-RW drives:
10 to 58 Hz: 0.019 mm / 58 to 500 Hz: 2.5 m/s
2
Burner can only be operated in an undisturbed environment
