Expansions and configuration
10.2 Memory expansion
SIMATIC Box PC 627
Operating Instructions, Release 05/2006, A5E00362052-03
10-5
Removing a memory module
How to remove a memory module
1 Open the device
2 Open the left and right interlocks
3 Pull the memory module out of the slot
4 Close the device.
Display of the current memory configuration
A new memory module is automatically detected. The allocation of the ”base memory and
extended memory” is automatically displayed when you switch on the device.
