Siemens SIMATIC CN 4100 - Page 64

Article number 6DL4178-0BH01-0XX0
• Runtime license required
No
• OPC UA Client
Yes
– Security policies
Yes
– User authentication
Yes; "anonymous" or by user name & password
– Number of connections, max.
5
– Number of nodes of the client interfaces,
max.
2 500
• OPC UA Server
No
Standards, approvals, certi󹪝cates
CE mark Yes
UKCA mark Yes
cULus Yes
Ambient conditions
Ambient temperature during operation
• horizontal installation, min.
-30 °C
• horizontal installation, max.
60 °C
• vertical installation, min.
-30 °C
• vertical installation, max.
45 °C
Dimensions
Width 45 mm
Height 185 mm
Depth 112 mm
Weights
Weight, approx. 0.44 kg
Approvals
EMC
Emission of radio frequency interference according
to IEC61000-6-4, EN 55016
Limit class A, for use in industrial environments
Received interference signals According to IEC 61000-6-5
Degree of protection and protection class
Degree of protection according to DIN EN 60529 IP20
Ambient conditions, tested according to IEC 61131-2
Ambient temperature during operation, tested according to IEC 60068-2
• Min.
• Max.
• -30 °C
• 60 °C with horizontal mounting; 45 °C with ver‐
tical mounting
Technical speci󹪝cations
10.2 Technical speci󹪝cations of components
CN 4100 Communication System
64 Equipment Manual, 10/2021, A5E50871363-AA
