Siemens SIMATIC CPU 410 User Manual

Technical data
16.1 Technical specifications of CPU 410-5H; (6ES7410-5HX08-0AB0)
CPU 410 Process Automation/CPU 410 SMART
System Manual, 05/2017, A5E31622160-AC
257
Article number
6ES7410-5HX08-0AB0
Functionality
• PROFIBUS DP master
Yes
• PROFIBUS DP slave
No
DP master
• Number of connections, max.
16
• Transmission rate, max.
12 Mbit/s
• Number of DP slaves, max.
96
• Number of slots per interface, max.
1 632
Services
– PG/OP communication
Yes
– Routing
Yes; S7 routing
– Global data communication
No
– S7 basic communication
No
– S7 communication
Yes
– S7 communication, as client
Yes
– S7 communication, as server
Yes
– Equidistance
No
– Isochronous mode
No
– SYNC/FREEZE
No
– Activation/deactivation of DP slaves
Yes; Single mode only
– Direct data exchange (slave-to-slave
communication)
No
– DPV1
Yes
Address area
– Inputs, max.
6 kbyte; up to 2 800 IOs (channels)
– Outputs, max.
6 kbyte; up to 2 800 IOs (channels)
User data per DP slave
– User data per DP slave, max.
244 byte
– Inputs, max.
244 byte
– Outputs, max.
244 byte
– Slots, max.
244
– per slot, max.
128 byte
2. Interface
Interface type
PROFINET
Physics
Ethernet RJ45
Isolated
Yes
automatic detection of transmission rate
Yes; Autosensing
Autonegotiation
Yes
