Compatibilities between the IM 153-x
A.2 Compatibilities between the versions of IM 153-2 / -2 FO
ET 200M
Operating Instructions, 12/2008, EWA-4NEB780600602-08
245
Configurable FM in a configuration with IM 153-2
For the distributed use of the FM 353 / 354 / 355 with full S7 functionality you can use the
following CPUs and FMs only as of the specified order numbers and module versions.
CPUs and FMs not listed in the table (e.g. CPU 316-2 DP) can be used as of the respective
first module version.
Table A- 2 Restrictions for DP master CPUs and FM for IM 153-2
Module as of order no. ... with module version Operating system update is
possible as of version module
CPU 315-2 DP 6ES7315-2AF01-0AB0 03 01
CPU 413-2 DP 6ES7413-2XG01-0AB0 02 01
CPU 414-2 DP 6ES7414-2XG01-0AB0
6ES7414-2XJ00-0AB0
02
04
01
03
CPU 416-2 DP 6ES7416-2XK00-0AB0
6ES7416-2XL00-0AB0
04
04
03
03
FM 353
FM 354
FM 355C
FM 355S
6ES7353-1AH01-0AE0
6ES7354-1AH01-0AE0
6ES7355-0VH10-0AE0
6ES7353-1VH10-0AE0
01
01
01
01
–
–
–
–
Configuration of the IM 153-2 with the general ID format (AKF)
You can also configure the IM 153-2 as of order number 6ES7153-2AA02-0XB0, module
version 07, and 6ES7153-2AB01-0XB0, module version 06, with the general ID format AKF.
This configuration assumes detailed knowledge of the structure of the AKF. You must use
the code 0x00 for the slots 1 to 3.
WARNING
If you conduct the configuration with the general ID format AKF, the quality of the
comparison of the preset and actual configuration when the DP slave starts up or when
removing or inserting modules is very low. Since there is no type ID available for the
comparison, an incorrect configuration cannot be easily detected!
Functionality of the Previous Version
If you insert the IM 153-2Bx00 interface module
● on a bus module BM IM/IM (6ES7195-7HD00-0XA0),
● configure as an IM 153-2AA02 / -2AB01 with
STEP 7
,
● configure with GSD revision 2,
then it has the functionality of an IM 153-2AA02 / -2AB01.
