Product overview
2.1 Distributed I/O – overview
ET 200MP Distributed I/O System
14 System Manual, 01/2013, A5E03723484-01
Configuration of a PROFINET IO network
The figure below illustrates a typical PROFINET IO network configuration. Existing
PROFIBUS slaves can be integrated using an IE/PB Link.
,2FRQWUROOHU
,2GHYLFH,2GHYLFH
03
LQFK7RXFK
3*
,QGXVWULDO(WKHUQHW
,(3%OLQN
,2GHYLFH
,2GHYLFH
352),%86'3
352),1(7,2
(76
(7HFR31
6
(70(703
(763
Figure 2-1 Typical configuration of PROFINET IO
Note
ET 200MP modules can only be connected to the S7-1200 via GSD/GSDML.
