Module overview
3.5 Analog output modules
ET 200MP Distributed I/O System
System Manual, 01/2013, A5E03723484-01
27
3.5 Analog output modules
Overview of properties
The table below shows the essential properties of the analog output modules.
Table 3- 6 Analog output modules
Order no.: 6ES7532-5HD00-0AB0 6ES7532-5HF00-0AB0
Short description AQ 4xU/I ST AQ 8xU/I HS
Number of outputs 4 8
Resolution 16 bits (including sign) 16 bits (including sign)
Output type Voltage
Current
Voltage
Current
Electrical isolation between channels No No
Rated supply voltage 24 V DC 24 V DC
Diagnostic interrupt Yes Yes
Isochronous mode supported No Yes
Reference
Additional information on the technical specifications of the modules is available in the
respective manuals.
3.6 Power supply modules
Overview of properties
The table below shows the essential properties of the power supply modules.
Table 3- 7 Power supply modules
Order no.: 6ES7505-0KA00-0AB0 6ES7505-0RA00-0AB0 6ES7507-0RA00-0AB0
Short description PS 25W 24V DC PS 60W 24/48/60V DC PS 60W 120/230V AC/DC
Rated input voltages 24 V DC 24 V DC, 48 V DC, 60 V DC 120 V AC, 230 V AC
120 V DC, 230 V DC
Output power 25 W 60 W 60 W
Electrical isolation from the
backplane bus
Yes Yes Yes
Diagnostic interrupt Yes Yes Yes
Reference
Additional information on the technical specifications of the modules is available in the
respective manuals.
