6.7 Connecting PROFINET IO via the RJ45 bus connector to the interface module
ET 200MP Distributed I/O System
System Manual, 01/2013, A5E03723484-01
61
6.7 Connecting PROFINET IO via the RJ45 bus connector to the
interface module
Introduction
You connect PROFINET IO to the interface module via the RJ45 bus cable connector.
PROFINET IO can be further looped via the integrated 2-port switch.
Required accessories
● The order number of the bus cable connector is listed in the chapter Accessories / Spare
Parts (Page 113).
● Please observe the spe
cifications in the PROFINET Installation Guide
(http://www.profibus.com
).
