ET 200MP Distributed I/O System
System Manual, 01/2013, A5E03723484-01
77
Configuring
7
Introduction
You configure and assign parameters to the ET 200MP (interface module and I/O modules)
with STEP 7 or in the configuration software of another manufacturer.
Requirements
Table 7- 1 Requirements
Configuration software Requirements Installation information
STEP 7
(TIA Portal) V12 and
above
- STEP 7 online help
STEP 7 V5.5 SP3 and above STEP 7 online help
Software of another manufacturer
GSD file: GSDML-Vx.y-siemens-et200mp-"Date in
format yyyymmdd".xml
(http://support.automation.siemens.com/WW/view/en
/19698639/130000)
Manufacturer documentation
* The TIA Portal supports GSDML specification V2.25. The ET 200MP is delivered with a GSD file based on specification
V2.3. The GSD file can be installed and used in the TIA Portal.
Configuration of the ET 200MP
Observe the STEP 7 online help and/or the documentation of the configuration software
manufacturer.
7.1 Selection of the power supply (PS) module
Whether you require an additional power supply (PS) module for your assembly, depends on
the power consumption by all I/O modules from the backplane bus. The power budget
calculation balances the power provided by the interface module and the power supply (PS)
module(s) via the backplane bus, against the required power for the I/O modules.
● If you use STEP 7 (TIA Portal) V12 and above to plan your configuration, you will be
supported in the power budget calculation with corresponding advice.
● If you use the GSD file for ET 200MP to plan your configuration, you must perform the
power budget calculation manually.
See the chapters Power budget calculation (Page 32) and Setting up power segments
(Page 36).
Reference
Further information on the performance values (power feed, power consumption) of the
interface module, of the power supply module, and of the I/O modules can be found in the
Product Manuals of the respective modules.
