ET 200MP Distributed I/O System
System Manual, 01/2013, A5E03723484-01
23
Module overview
3
3.1 Interface modules
Overview of properties
The table below shows the essential properties of the interface modules.
Table 3- 1 Interface module
Order no.: 6ES7155-5AA00-0AB0
Short description IM 155-5 PN ST
Supply voltage, permitted range 20.4 V DC to 28.8 V DC
Interfaces 1 x PROFINET; integrated 2-port switch
Isochronous real-time communication supported Yes
Prioritized startup Yes; 500 ms
Device replacement without programming device Yes (LLDP; address assignment with tool, e. g. the TIA Portal)
Media redundancy Yes
Shared Device Yes; 2 IO controllers
Isochronous mode supported Yes; shortest cycle 250 µs
Identification data I&M 0 to 3
Reference
Additional information on the technical specifications of the interface modules is available in
the respective manuals.
