Module overview
3.3 Digital output modules
ET 200MP Distributed I/O System
System Manual, 01/2013, A5E03723484-01
25
Table 3- 4 Digital output modules
Order no.: 6ES7522-5HF00-0AB0 6ES7522-5FF00-0AB0
Short description DQ 8x230VAC/5A ST DQ 8x230VAC/2A ST
Number of outputs 8 8
Type Relay Triac
Electrical isolation between
channels
Yes Yes
Number of potential groups 8 8
Relay coil supply voltage 24 V DC ---
Rated output voltage 230 V AC 230 V AC
Rated output current 5 A 2 A
Diagnostic interrupt Yes No
Isochronous mode supported No No
Reference
Additional information on the technical specifications of the modules is available in the
respective manuals.
