Parameter data records
A.2 Structure of the parameter data record 128 for the entire module
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
105
Error code in STATUS parame-
ter
(hexadecimal)
DF 80 E1 21 Parameter for user data variant not possi-
ble.
Check Byte 9. Select a different user data
variant or change the configuration.
DF 80 E1 22 Parameter for user data variant is invalid. Check Byte 9. Select a valid code for the
DF 80 E1 23 Parameter for frequency is invalid. Check Byte 6. Enter valid values.
DF 80 E1 24 Parameter for tolerance line voltage is
Check Byte 7. Enter valid values.
DF 80 E1 25 Parameter for current transformer second-
Check Bit 4...5 in Byte 22, 42...62. Enter
DF 80 E1 29 Parameter for tolerance factor overcurrent
Check Byte 15, 35...55. Enter valid values.
DF 80 E1 2A Parameter for tolerance time overcurrent
Check Byte 16...17, 36...37, 56...57. Enter
DF 80 E1 2B Parameter for low limit measuring current
Check Byte 23, 43...63. Enter valid values.
DF 80 E1 2C Parameter for current transformer primary
Check Byte 18...21, 38...41, 48...61. Enter
DF 80 E1 2D Parameter for voltage converter primary
Check Byte 26...29, 46...49, 66...69. Enter
DF 80 E1 2E
Parameter for voltage converter secondary
voltage invalid.
Check Byte 24...25, 44...45, 64...65. Enter
DF 80 E1 2F Parameter for full-scale value for energy
counters invalid.
Check Bit 4...6 in Byte 6. Enter valid val-
ues.
DF 80 E1 30 Invalid data record number. Check the data record number. Enter a
valid data record number.
DF 80 E1 3E Only for connection type 3P4W1.
Parameters for the different phases are not
identical.
Check Bytes 14...33, 34...53, 54...73. En-
ter identical values at all three phases.
DF 80 E1 3F Full-scale value for energy counter too
small or transmission ratio of current and
Increase the full-scale value or reduce the
transmission ratio of the current and volt-
