Parameter data records
A.4 Structure of the parameter data record 130 for user-data mapping
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
111
Parameter block for user data mapping
The following diagram shows the structure of the parameter blocks for user data mapping.
Image A-12 Parameter block for user data mapping
