Measured variables
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
114 Manual, 12/2015, A5E36061895-AA
Meas-
ured
value ID
Measured variables
Data
type
Unit
Value range
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
30
Frequency
4
REAL
Hz
45.0 ... 65.0
✓
✓
✓
✓
✓
34 Total apparent power
L1L2L3
5
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
35 Total active power
L1L2L3
5
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
36 Total reactive power
L1L2L3
5
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
37 Total power factor
L1L2L3
6 7
REAL - 0.0 ... 1.0 ✓ ✓ ✓ ✓ ✓
38 Amplitude balance for
voltage
2
REAL % 0 ... 100 ✓ ✓
39 Amplitude symmetry for
current
2
REAL % 0 ... 200 ✓ ✓
40
Max. voltage UL1-N
6
REAL
V
0.0 ... 1000000.0
✓
✓
✓
✓
✓
41
Max. voltage UL2-N
6
REAL
V
0.0 ... 1000000.0
✓
✓
✓
✓
42
Max. voltage UL3-N
6
REAL
V
0.0 ... 1000000.0
✓
✓
✓
43
Max. voltage UL1-UL2
6
REAL
V
0.0 ... 1000000.0
✓
✓
44
Max. voltage UL2-UL3
6
REAL
V
0.0 ... 1000000.0
✓
✓
45
Max. voltage UL3-UL1
6
REAL
V
0.0 ... 1000000.0
✓
✓
46
Max. current L1
6
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
✓
47 Max. current L2
6
REAL A 0.0 ... 100000.0 ✓ ✓ ✓ ✓
48
Max. current L3
6
REAL
A
0.0 ... 100000.0
✓
✓
✓
49 Max. apparent power L1
6
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
50 Max. apparent power
L2
6
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓
51 Max. apparent power
L3
6
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓
52 Max. active power L1
6
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
53 Max. active power L2
6
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓
54 Max. active power L3
6
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓
55 Max. reactive power L1
6
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
56 Max. reactive power L2
6
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓
57 Max. reactive power L3
6
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓
58
Max. power factor L1
6
REAL
-
0.0 ... 1.0
✓
✓
✓
✓
✓
59
Max. power factor L2
6
REAL
-
0.0 ... 1.0
✓
✓
✓
✓
60
Max. power factor L3
6
REAL
-
0.0 ... 1.0
✓
✓
✓
61
Max. frequency
6
REAL
Hz
45.0 ... 65.0
✓
✓
✓
✓
✓
