Measured variables
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
115
Meas-
ured
value ID
Measured variables
Data
type
Unit
Value range
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
65 Max. total apparent
power
6
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
66 Max. total active power
6
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
67 Max. total reactive
power
6
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
68
Max. total power factor
6
REAL
-
0.0 ... 1.0
✓
✓
✓
✓
✓
70
Min. voltage UL1-N
6
REAL
V
0.0 ... 1000000.0
✓
✓
✓
✓
✓
71
Min. voltage UL2-N
6
REAL
V
0.0 ... 1000000.0
✓
✓
✓
✓
72
Min. voltage UL3-N
6
REAL
V
0.0 ... 1000000.0
✓
✓
✓
73
Min. voltage UL1-UL2
6
REAL
V
0.0 ... 1000000.0
✓
✓
74
Min. voltage UL2-UL3
6
REAL
V
0.0 ... 1000000.0
✓
✓
75
Min. voltage UL3-UL1
6
REAL
V
0.0 ... 1000000.0
✓
✓
76
Min. current L1
6
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
✓
77
Min. current L2
6
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
78
Min. current L3
6
REAL
A
0.0 ... 100000.0
✓
✓
✓
79 Min. apparent power L1
6
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
80 Min. apparent power L2
6
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓
81 Min. apparent power L3
6
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓
82 Min. active power L1
6
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
83 Min. active power L2
6
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓
84 Min. active power L3
6
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓
85 Min. reactive power L1
6
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
86 Min. reactive power L2
6
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓
87 Min. reactive power L3
6
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓
88
Min. power factor L1
6
REAL
-
0.0 ... 1.0
✓
✓
✓
✓
✓
89
Min. power factor L2
6
REAL
-
0.0 ... 1.0
✓
✓
✓
✓
90
Min. power factor L3
6
REAL
-
0.0 ... 1.0
✓
✓
✓
91
Min. frequency
6
REAL
Hz
45.0 ... 65.0
✓
✓
✓
✓
✓
95 Min. total apparent p
ower
6
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
96 Min. total active power
6
REAL W -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
97 Min. total reactive power
6
REAL var -3.0 x 10
9
…
+3.0 x 10
9
✓ ✓ ✓ ✓ ✓
