Measured variables
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
117
Meas-
ured
value ID
Measured variables
Data
type
Unit
Value range
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
61180
Active energy inflow L1
6
LREAL
Wh
0.0 ... 1.8 x 10
308
✓
✓
✓
✓
✓
61181 Active energy outflow
L1
6
LREAL Wh 0.0 ... 1.8 x 10
308
✓ ✓ ✓ ✓ ✓
61182 Reactive energy inflow
L1
6
LREAL varh 0.0 ... 1.8 x 10
308
✓ ✓ ✓ ✓ ✓
61183 Reactive energy outflow
L1
6
LREAL varh 0.0 ... 1.8 x 10
308
✓ ✓ ✓ ✓ ✓
61184
Apparent energy L1
6
LREAL
VAh
0.0 ... 1.8 x 10
308
✓
✓
✓
✓
✓
61185
Active energy L1
6
LREAL
Wh
0.0 ... 1.8 x 10
308
✓
✓
✓
✓
✓
61186
Reactive energy L1
6
LREAL
varh
0.0 ... 1.8 x 10
308
✓
✓
✓
✓
✓
61190 Overflow counter active
energy inflow L1
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓ ✓
61191 Overflow counter active
energy outflow L1
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓ ✓
61192 Overflow counter reac-
tive energy inflow L1
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓ ✓
61193 Overflow counter reac-
tive energy outflow L1
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓ ✓
61194 Overflow counter appar-
ent energy L1
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓ ✓
61198
Phase angle L2
3
REAL
°
0.0 ... 360.0
✓
✓
✓
✓
61200
Active energy inflow L2
6
LREAL
Wh
0.0 ... 1.8 x 10
308
✓
✓
✓
✓
61201 Active energy outflow
L2
6
LREAL Wh 0.0 ... 1.8 x 10
308
✓ ✓ ✓ ✓
61202 Reactive energy inflow
L2
6
LREAL varh 0.0 ... 1.8 x 10
308
✓ ✓ ✓ ✓
61203 Reactive energy outflow
L2
6
LREAL varh 0.0 ... 1.8 x 10
308
✓ ✓ ✓ ✓
61204
Apparent energy L2
6
LREAL
VAh
0.0 ... 1.8 x 10
308
✓
✓
✓
✓
61205
Active energy L2
6
LREAL
Wh
0.0 ... 1.8 x 10
308
✓
✓
✓
✓
61206
Reactive energy L2
6
LREAL
varh
0.0 ... 1.8 x 10
308
✓
✓
✓
✓
61210 Overflow counter active
energy inflow L2
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓
61211 Overflow counter active
energy outflow L2
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓
61212 Overflow counter reac-
tive energy inflow L2
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓
61213 Overflow counter reac-
tive energy outflow L2
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓
61214 Overflow counter appar-
ent energy L2
6
UINT - 0 ... 65535 ✓ ✓ ✓ ✓
61218
Phase angle L3
3
REAL
0.0 ... 360.0
✓
✓
✓
61220
Active energy inflow L3
6
LREAL
Wh
0.0 ... 1.8 x 10
308
✓
✓
✓
