Siemens simatic et200sp User Manual

Measured variables
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
118 Manual, 12/2015, A5E36061895-AA
Meas-
ured
value ID
Measured variables
Data
type
Unit
Value range
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
61221 Active energy outflow
L3
6
LREAL Wh 0.0 ... 1.8 x 10
308
✓ ✓ ✓
61222 Reactive energy inflow
L3
6
LREAL varh 0.0 ... 1.8 x 10
308
✓ ✓ ✓
61223 Reactive energy outflow
L3
6
LREAL varh 0.0 ... 1.8 x 10
308
✓ ✓ ✓
61224
Apparent energy L3
6
LREAL
VAh
0.0 ... 1.8 x 10
308
✓
✓
✓
61225
Active energy L3
6
LREAL
Wh
0.0 ... 1.8 x 10
308
✓
✓
✓
61226
Reactive energy 7L3
6
LREAL
varh
0.0 ... 1.8 x 10
308
✓
✓
✓
61230 Overflow counter active
energy inflow L3
6
UINT - 0 ... 65535 ✓ ✓ ✓
61231 Overflow counter active
energy outflow L3
6
UINT - 0 ... 65535 ✓ ✓ ✓
61232 Overflow counter reac-
tive energy inflow L3
6
UINT - 0 ... 65535 ✓ ✓ ✓
61233 Overflow counter reac-
tive energy outflow L3
6
UINT - 0 ... 65535 ✓ ✓ ✓
61234 Overflow counter appar-
ent energy L3
6
UINT - 0 ... 65535 ✓ ✓ ✓
62110
Active energy inflow L1
6
UDINT
Wh
0 ... 4294967295
✓
✓
✓
✓
✓
62111 Active energy outflow L1
6
UDINT Wh 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
62112 Reactive energy inflow
L1
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
62113 Reactive energy outflow
L1
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
62114
Apparent energy L1
6
UDINT
Wh
0 ... 4294967295
✓
✓
✓
✓
✓
62115 Active energy L1 total
(inflow - outflow)
6
UDINT Wh 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
62116 Reactive energy L1 total
(inflow - outflow)
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
62210
Active energy inflow L2
6
UDINT
Wh
0 ... 4294967295
✓
✓
✓
✓
62211 Active energy outflow
L2
6
UDINT Wh 0 ... 4294967295 ✓ ✓ ✓ ✓
62212 Reactive energy inflow
L2
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓ ✓
62213 Reactive energy outflow
L2
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓ ✓
62214
Apparent energy L2
6
UDINT
VAh
0 ... 4294967295
✓
✓
✓
62215 Active energy L2 total
(inflow - outflow)
6
UDINT Wh 0 ... 4294967295 ✓ ✓ ✓ ✓
62216 Reactive energy L2 total
(inflow - outflow)
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓ ✓
62310 Active energy inflow L3
6
UDINT Wh 0 ... 4294967295 ✓ ✓ ✓
