Siemens simatic et200sp User Manual

Measured variables
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
119
Meas-
ured
value ID
Measured variables
Data
type
Unit
Value range
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
62311 Active energy outflow
L3
6
UDINT Wh 0 ... 4294967295 ✓ ✓ ✓
62312 Reactive energy inflow
L3
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓
62313 Reactive energy outflow
L3
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓
62314
Apparent energy L3
6
UDINT
VAh
0 ... 4294967295
✓
✓
✓
62315 Active energy L3 total
(inflow - outflow)
6
UDINT Wh 0 ... 4294967295 ✓ ✓ ✓
62316 Reactive energy L3 total
(inflow - outflow)
6
UDINT Varh 0 ... 4294967295 ✓ ✓ ✓
65500 Qualifier L1 WORD Bit field 0b 00 00 00 00
0b qq 00 00 xx
✓ ✓ ✓ ✓ ✓
65501 Qualifier L2 WORD Bit field 0b 00 00 00 00
0b qq 00 xx 00
✓ ✓ ✓ ✓
65502 Qualifier L3 WORD Bit field 0b 00 00 00 00
0b qq xx 00 00
✓ ✓ ✓
65503 Qualifier L1L2L3 WORD Bit field 0b 00 00 00 00
0b qq xx xx xx
✓ ✓ ✓ ✓ ✓
65504 Total operating hours
counter L1L2L3
5 8 9
REAL h 0.0 ... 3.4 x 10
38
✓ ✓ ✓ ✓ ✓
65505 Operating hours counter
L1
5
REAL h 0.0 ... 3.4 x 10
38
✓ ✓ ✓ ✓ ✓
65506 Operating hours counter
L2
5
REAL h 0.0 ... 3.4 x 10
38
✓ ✓ ✓ ✓
65507 Operating hours counter
L3
5
REAL h 0.0 ... 3.4 x 10
38
✓ ✓ ✓
65508 Status of energy counter
overflows
WORD Bit field 0x xxxx xxxx ✓ ✓ ✓ ✓ ✓
65509
Status of limits
WORD
Bit field
0x xxxx xxxx
✓
✓
✓
✓
✓
65510 Counter limit violation
GW1
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65511 Counter limit violation
GW2
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65512 Counter limit violation
GW3
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65513 Counter limit violation
GW4
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65514 Counter limit violation
GW5
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65515 Counter limit violation
GW6
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65516 Counter limit violation
GW7
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
