Siemens simatic et200sp User Manual

Measured variables
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
120 Manual, 12/2015, A5E36061895-AA
Meas-
ured
value ID
Measured variables
Data
type
Unit
Value range
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
65517 Counter limit violation
GW8
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65518 Counter limit violation
GW9
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65519 Counter limit violation
GW10
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65520 Counter limit violation
GW11
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65521 Counter limit violation
GW12
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65522 Counter limit violation
GW13
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65523 Counter limit violation
GW14
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65524 Counter limit violation
GW15
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
65525 Counter limit violation
GW16
5
UDINT 0 ... 4294967295 ✓ ✓ ✓ ✓ ✓
66001
Voltage UL1-N
1
UINT
0.01 V
0 ... 65535
✓
✓
✓
✓
✓
66002
Voltage UL2-N
1
UINT
0.01 V
0 ... 65535
✓
✓
✓
✓
66003
Voltage UL3-N
1
UINT
0.01 V
0 ... 65535
✓
✓
✓
66004
Voltage UL1-L2
2
UINT
0.01 V
0 ... 65535
✓
✓
66005
Voltage UL2-L3
2
UINT
0.01 V
0 ... 65535
✓
✓
66006
Voltage UL3-L1
2
UINT
0.01 V
0 ... 65535
✓
✓
66007
Current L1
1
UINT
1 mA
0 ... 65535
✓
✓
✓
✓
✓
66008 Current L2
1
UINT 1 mA 0 ... 65535 ✓ ✓ ✓ ✓
66009
Current L3
1
UINT
1 mA
0 ... 65535
✓
✓
✓
66010
Apparent power L1
3
INT
1 VA
-27648 ... 27648
✓
✓
✓
✓
✓
66011
Apparent power L2
3
INT
1 VA
-27648 ... 27648
✓
✓
✓
✓
66012
Apparent power L3
3
INT
1 VA
-27648 ... 27648
✓
✓
✓
66013
Active power L1
3
INT
1 W
-27648 ... 27648
✓
✓
✓
✓
✓
66014
Active power L2
3
INT
1 W
-27648 ... 27648
✓
✓
✓
✓
66015
Active power L3
3
INT
1 W
-27648 ... 27648
✓
✓
✓
66016
Reactive power L1
3
INT
1 var
-27648 ... 27648
✓
✓
✓
✓
✓
66017
Reactive power L2
3
INT
1 var
-27648 ... 27648
✓
✓
✓
✓
66018
Reactive power L3
3
INT
1 var
-27648 ... 27648
✓
✓
✓
66019
Power factor L1
3
USINT
0.01
0 ... 100
✓
✓
✓
✓
✓
66020
Power factor L2
3
USINT
0.01
0 ... 100
✓
✓
✓
✓
66021
Power factor L3
3
USINT
0.01
0 ... 100
✓
✓
✓
66030
Frequency
4
USINT
1 Hz
45 ... 65
✓
✓
✓
✓
✓
66034 Total apparent power
L1L2L3
5
INT 1 VA -27648 ... 27648 ✓ ✓ ✓ ✓ ✓
