Parameters
12.1 Parameters
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
77
Parameters
Value range
Default setting
Reconfigura-
tion in RUN
Effective range with configuration
software, e.g. STEP 7 (TIA Portal)
GSD file
PROFINET IO
GSD file
PROFIBUS DP
Connection type
• Disabled
• 1P2W - 1-phase
alternating current
• 3x1P2W - 3x1
phase, 2 conductors
each
• 2P3W - 2 phases, 3
conductors
• 3P4W - 3 phases, 4
conductors
• 3P4W1 - 3 phases, 4
conductors, bal-
anced load
3P4W - 3 phases,
4 conductors
Yes
Module
Module
(only 1P2W,
3P4W, 3P4W1
and deactivat-
ed)
Voltage measuring
range
• 100 V
• 110 V
• 115 V
• 120 V
• 127 V
• 190 V
• 200 V
• 208 V
• 220 V
• 230 V
• 240 V
• 277 V
230 V
Yes
Module
Module
Line voltage tolerance
[%]
• 1 ... 50 %
10 %
Yes
Module
Module
Line frequency
• 50 Hz
• 60 Hz
50 Hz
Yes
Module
Module
Enable gate energy
counter
• No
• Yes
No
Yes
Module
-
