Parameters
12.1 Parameters
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
78 Manual, 12/2015, A5E36061895-AA
Parameters
Value range
Default setting
Reconfigura-
tion in RUN
Effective range with configuration
software, e.g. STEP 7 (TIA Portal)
GSD file
PROFINET IO
GSD file
PROFIBUS DP
Full-scale value for
energy counter
• No full-scale value -
infinite counting
• 10
3
- count periodi-
cally
• 10
6
- count periodi-
cally
• 10
9
- count periodi-
cally
• 10
12
- count periodi-
cally
• 10
15
- count periodi-
cally
No full-scale value
- infinite counting
Yes
Module
-
(Default setting.
No full-scale
value - infinite
counting)
User data variant
See the table Overview
of the user data variants
(Page 135)
Total energy L1 L2
L3 (ID 254 or FE
H
)
Yes
Module
Module
(only user data
variant FE
H
,
FA
H
, F9
H
, F8
H
,
9F
H
, F5
H
, 80
H
)
Minimum and maxi-
mum value calculation
• Disable
• Enable
Disable Yes Module -
(Default setting:
Disable)
Diagnostics
overflow current
• Disable
• Enable
Disable
Yes
Channel/phase
Module
Diagnostics
overflow voltage
• Disable
• Enable
Disable Yes Channel/phase Module
Diagnostics
underflow voltage
• Disable
• Enable
Disable
Yes
Channel/phase
Module
Diagnostics
low limit voltage
• Disable
• Enable
Disable Yes Channel/phase -
(blocking is
preset)
Diagnostics
overflow cumulative
values
• Disable
• Enable
Disable
Yes
Channel/phase
Module
Overcurrent tolerance
factor [0.1 A]
• 10 ... 100 [0.1 A]
100 [0.1 A] Yes Channel/phase Module
Overcurrent tolerance
time [ms]
• 1 ... 60000 ms
40000 ms
Yes
Channel/phase
Module
Low limit for current
measurement [mA]
• 2 ... 250 mA
50 mA
Yes
Channel/phase
-
(Default setting:
2 mA)
Operating hours coun-
ter
• Disable
• Enable
Disable
Yes
Channel/phase
-
(Default setting:
Disable)
