Siemens simatic et200sp User Manual

Parameters
12.1 Parameters
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
79
Parameters
Value range
Default setting
Reconfigura-
tion in RUN
Effective range with configuration
software, e.g. STEP 7 (TIA Portal)
GSD file
PROFINET IO
GSD file
PROFIBUS DP
Enable gate of operat-
ing hours counter
• No
• Yes
No
Yes
Channel/phase
-
Current transformer
primary current [A]
• 1 ... 99999 A
1 A
Yes
Channel/phase
Module
(Value range:
1...65535)
Current transformer
secondary current
• 1 A
• 5 A
1 A
Yes
Channel/phase
Module
Voltage transformer
primary voltage [V]
• 1 ... 999999 V
230 V
Yes
Channel/phase
Module
Voltage transformer
secondary voltage [V]
• 1 ... 500 V
230 V
Yes
Channel/phase
-
(same value as
Voltage meas-
uring range
parameter)
Reverse current direc-
tion
• Disable
• Enable
Disable
Yes
Channel/phase
Module
Number of limits
• 0 ... 16
0 Yes Module -
Limit monitoring for limit
• Disable
• Enable
Disable
Yes
Module
-
Measured variable for
limit
• Measured value ID,
see Table B-1
None Yes Limit -
Gate for limit via DQ
• Disable
• Enable
Disable
Yes
Channel/phase
-
Hardware interrupt for
limit
• Disable
• Enable
Disable Yes Channel/phase -
Limit
• depending on the
selected measured
variable
0
Yes
Limit
-
Type of limit
• High limit
• Low limit
High limit Yes Channel/phase -
Hysteresis for limit
monitoring [%]
• 0 ... 200 [0.1%]
0%
Yes
Channel/phase
-
Delay time for limit
monitoring [s]
• 0 ... 10 s
0 s Yes Channel/phase -
Number of measured
values for user data
mapping
• 0 ... 64
0
Yes
Module
-
(no user data
mapping)
Measured variable
• Measured value ID,
see Table B-1
None Yes Measured vari-
able
-
(no user data
mapping)
