Technical specifications
14.1 Technical specifications
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
94 Manual, 12/2015, A5E36061895-AA
Frequency measurement, min.
45 Hz
Frequency measurement, max.
65 Hz
Measuring inputs for voltage
Measurable line voltage between phase and
neutral conductor
277 V
Measurable line voltage between the line con-
ductors
480 V
Measurable line voltage between phase and
neutral conductor, min.
90 V
Measurable line voltage between phase and
neutral conductor, max.
293 V
Measurable line voltage between the line con-
ductors, min.
155 V
Measurable line voltage between the line con-
ductors, max.
508 V
Measuring category for voltage measurement
in accordance with IEC 61010-2-030
CAT II. CAT III with prescribed protective ele-
ments
Internal resistance line conductor and N-
conductor
3.4 mΩ
Power consumption, per phase
20 mW
Surge voltage strength 1.2/50µs
1 kV
Measuring inputs for current
Relative measurable current for AC, min.
1%; in relation to the secondary rated current 5 A
Relative measurable current for AC, max.
100%
; in relation to the secondary rated current 5
A
Continuous current for AC, maximum permis-
sible
5 A
Apparent power consumption per phase for
measuring range 5 A
0.6 VA
Rated value of short-time current carrying
capacity is restricted to 1 s
100 A
Input resistance measuring range 0 to 5 A
25 mΩ; at the terminal
Zero point suppression
Configurable: 2 - 250 mA, default 50 mA
Impulse withstand capability
10 A; for 1 minute
