Technical specifications
14.1 Technical specifications
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
95
6ES7134-6PA20-0BD0
Accuracy class to IEC 61557-12
•
Measured variable voltage
0.2
•
Measured variable current
0.2
•
Measured variable apparent power
0.5
•
Measured variable active power
0.5
•
Measured variable reactive power
1
•
Measured variable power factor
0.5
•
Measured variable active energy
0.5
•
Measured variable reactive energy
1
•
Measured variable neutral current
0.5. Calculated
•
Measured variable phase angle
+/-1°. Not covered by IEC 61577-12
•
Measured variable frequency
0.05
Electrical isolation
Electrical isolation of channels
Between the channels and backplane bus
Yes. 3700 VAC (type test) CATIII
Insulation
Insulation tested with
2300 VAC 1 min. (type test)
Ambient conditions
Ambient temperature in operation
Horizontal mounting position, min.
0 °C
Horizontal mounting position, max.
60 °C
Vertical mounting position, min.
0 °C
Vertical mounting position, max.
50 ℃
Dimensions
Width
20 mm
Weights
Weight (without packaging)
45 g
Miscellaneous
Current transformer selection data
Cable length (clamp-type transformer) depending
on Zn and Imax
200 m
ATEX approval
In accordance with EN 60079-15 (Electrical apparatus for potentially explosive atmospheres;
Type of protection "n") and EN 60079-0 (Electrical apparatus for potentially explosive gas
atmospheres - Part 0: General Requirements)
Dimension drawing
See ET 200SP BaseUnits (http://support.automation.siemens.com/WW/view/en/59753521)
manual

Siemens simatic et200sp Specifications

General

Category	I/O Systems
Power Supply	24 V DC
Protection Rating	IP20
Number of Modules	Up to 64 modules
Mounting	DIN Rail
Communication Protocols	PROFINET, PROFIBUS
Storage Temperature	-40 °C to +70 °C
Digital Inputs	Yes (depending on module)
Digital Outputs	Yes (depending on module)
Analog Inputs	Yes (depending on module)
Analog Outputs	Yes (depending on module)
Modularity	Modular
Relative Humidity	5 to 95% (non-condensing)
Weight	Varies by configuration
System Type	Distributed I/O
