Siemens SIMATIC HMI KTP400 Basic User Manual

Technical specifications
8.9 Scope of functions with WinCC
Basic Panels 2nd Generation
116 Operating Instructions, 10/2016, A5E33293231-AB
Screens
Object
Specification
Quantity
Screens
Quantity
250
Fields per screen 100
Tags per screen
100
Template
Yes
Objects per screen
Complex objects
1
150
Recipe views
10
Trend views
8
User view
1
Alarm view
20
Diagnostics view
5
System diagnostics view
150
Multiple tags (array elements)
2
100
1
Complex objects include: bars, sliders, symbol library, clock and all objects from the Controls area.
2
This includes array elements contained in recipes.
Recipes
The specified values are maximum values and should not be used additive.
Object
Specification
Quantity
Recipes
Quantity
50
Elements per recipe
1
100
Data records per recipe
100
User data length in KB per data record
32
Reserved memory for data records in the internal Flash
256 KB
1
When arrays are used, each array element represents a recipe element.
Logging
Object
Specification
Quantity
Logs
Number of logs
2
Number of tags
10
Number of log entries
1
10,000
Number of segmented circular logs
400
Logging cycle
1 s
1
For the "segmented circular log" logging method, the number of entries applies to all sequential logs. The product
derived from the number of circular logs times the number of data records in this log may not be exceeded.

Siemens SIMATIC HMI KTP400 Basic Specifications

General

Display Type	TFT LCD
Resolution	480 x 272 pixels
Touchscreen	Yes
Backlighting	LED
Color Depth	16-bit
Power Supply	24 V DC
Mounting	Panel mounting
Operating Temperature	0 to 50 °C
Display Size	4.3 inches
Display Colors	65K colors
Power Consumption	Approx. 3.6 W
Protection Rating	IP65 (front)
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
Interfaces	PROFINET
