Operating the device
4.2 General functions of the screen keyboard
Basic Panels 2nd Generation
Operating Instructions, 10/2016, A5E33293231-AB
41
4.2
General functions of the screen keyboard
The following keys are available on the screen keyboard of all Basic HMI devices with touch
functionality:
Cursor left
Cursor right
Delete character on left
Cancel input
Delete character on right
Confirm input
Shift to upper case for the next character to be entered
Permanent shift to upper case, corresponds to the "CAPS LOCK" function.
Switchover to numeric keypad
Switchover to alphanumeric keypad
Display infotext
The infotext configured for the operating element is displayed.

Siemens SIMATIC HMI KTP400 Basic Specifications

General

Display Type	TFT LCD
Resolution	480 x 272 pixels
Touchscreen	Yes
Backlighting	LED
Color Depth	16-bit
Power Supply	24 V DC
Mounting	Panel mounting
Operating Temperature	0 to 50 °C
Display Size	4.3 inches
Display Colors	65K colors
Power Consumption	Approx. 3.6 W
Protection Rating	IP65 (front)
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
Interfaces	PROFINET
