Siemens SIMATIC HMI KTP400 Basic User Manual

Configuring the device
5.24 Setting the screen saver
Basic Panels 2nd Generation
Operating Instructions, 10/2016, A5E33293231-AB
71
5.24
Setting the screen saver
Note
Burn-in effect
The screen contents may leave a faint version (ghost) of the image in the background if they
appear for too long.
The "ghost" will disappear automatically after some time. The longer the same content is
displayed on the screen,
the longer it will take for the burn-in effect to disappear.
The screen saver helps to prevent burn
-in.
Always use the screen saver.
1.
Press "Screensaver" to open the
"Screensaver" dialog.
2.
Switch on the screensaver with
"Enable screensaver".
3.
Enter the number of minutes
with the selection wheel before
the screen saver is to be activated
under "Wait".
You may select values between
1 and 120 minutes.
4.
Use the "Brightness" slider to set
the screen brightne
ss for when the
screensaver is active.
Possible values:
0% (black screen), integer value
between 10% and 100%.

Siemens SIMATIC HMI KTP400 Basic Specifications

General

Display Type	TFT LCD
Resolution	480 x 272 pixels
Touchscreen	Yes
Backlighting	LED
Color Depth	16-bit
Power Supply	24 V DC
Mounting	Panel mounting
Operating Temperature	0 to 50 °C
Display Size	4.3 inches
Display Colors	65K colors
Power Consumption	Approx. 3.6 W
Protection Rating	IP65 (front)
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
Interfaces	PROFINET
