Mounting and connecting
3.1 Preparations
Basic Panels 2nd Generation
24 Operating Instructions, 10/2016, A5E33293231-AB
3.1.5
Making the mounting cutout
Note
Stability of the mounting cutout
The material in the area of the mounting
cutout must provide sufficient strength to guarantee
lasting and safe mounting of the HMI device.
To achieve the degrees of protection described below, it must be ensured that deformation
of the material cannot occur due to the force of the mounting clips
or operation of the device.
Degrees of protection
The degrees of protection of the HMI device can only be guaranteed if the following
requirements are met:
● Material thickness at the mounting cutout for a protection rating of IP65 or Front face only
Type 4X/Type 12 (indoor use only): 2 mm to 6 mm.
● Permitted deviation from plane at the mounting cutout: ≤ 0.5 mm
This condition must be met for the mounted HMI device.
● Permitted surface roughness in the area of the mounting seal: ≤ 120 µm (R
z
120)
Mounting compatibility
The mounting cutouts of the Basic panels are compatible with the mounting cutouts of the
following SIMATIC HMI devices:
Mounting cutout Basic Panel
Compatible with the mounting cutouts of the HMI device
KTP400 Basic
KTP400 Basic color PN
KTP700 Basic, KTP700 Basic DP
KTP600 Basic color PN; TP700 Comfort
KTP900 Basic
TP900 Comfort
KTP1200 Basic, KTP1200 Basic DP
TP1200 Comfort

Siemens SIMATIC HMI KTP400 Basic Specifications

General

Display Type	TFT LCD
Resolution	480 x 272 pixels
Touchscreen	Yes
Backlighting	LED
Color Depth	16-bit
Power Supply	24 V DC
Mounting	Panel mounting
Operating Temperature	0 to 50 °C
Display Size	4.3 inches
Display Colors	65K colors
Power Consumption	Approx. 3.6 W
Protection Rating	IP65 (front)
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
Interfaces	PROFINET
