Siemens SIMATIC HMI KTP400 Basic User Manual

Basic Panels 2nd Generation
Operating Instructions, 10/2016, A5E33293231-AB
21
Mounting and connecting
3
3.1
Preparations
3.1.1
Checking the package contents
Check the package content for visible signs of transport damage and for completeness.
Note
Damaged parts
Do not install parts damaged during shipment. In the case of damaged parts, contact your
Siemens representative.
The package content is described in section Scope of delivery (Page 14).
Keep the provided documentation in a safe place. The documentation is part of the HMI
device and is required for subsequent commissioning.
3.1.2
Checking the operating conditions
Note the information in the following sections of these operating instructions before installing
the HMI device:
● Certificates and approvals (Page 97)
● Electromagnetic compatibility (Page 99)
● Mechanical ambient conditions (Page 99)
● Climatic ambient conditions (Page 100)
● Information on insulation tests, protection class and degree of protection (Page 102)
● Technical specifications (Page 109)

Siemens SIMATIC HMI KTP400 Basic Specifications

General

Display Type	TFT LCD
Resolution	480 x 272 pixels
Touchscreen	Yes
Backlighting	LED
Color Depth	16-bit
Power Supply	24 V DC
Mounting	Panel mounting
Operating Temperature	0 to 50 °C
Display Size	4.3 inches
Display Colors	65K colors
Power Consumption	Approx. 3.6 W
Protection Rating	IP65 (front)
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
Interfaces	PROFINET
