Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
93
After you have started the diagnostics, all the transponders identified by the reader are listed
in the table (max. 500).
The output boxes:
● Identified transponders
Number of physically identified transponders (max. 500).
● Valid transponders
Number of identified transponders recognized by the reader as being valid since the start
of the recording and that were possibly further processed.
● Transponders in the field
Number of transponders located in the antenna field of the reader or the antenna during
the last inventory.
Select the "EPC-ID in ASCII format" check box to display the EPC-IDs of the transponders in
ASCII code.
Table 7- 24 Displayed properties of the recognized transponders
/ Selection of the transponders to be displayed in the graph.
Up to 10 transponders can be selected. The selected transponders are shown
in the RSSI graph as continuous lines. Up to 10 further transponders from the
list are displayed as dots.
/ / Filter status of the transponders
• Transponder was identified and returned to the user application.
• Transponder was identified but filtered out. Place the mouse pointer over
the symbol to find out which filter filtered out the transponder.
• Transponder was identified and not filtered out. However the transponder
has not yet been returned to the user application (e.g. due to the
"Glimpsed" status).
ID of the identified transponder
Antenna Antenna(s) with which the transponder was identified.
Min. power Minimum radiated power [dBm] of the antenna with which the transponder was
Power Radiated power [dBm] of the antenna with which the transponder was last
Last measured RSSI value of the transponder
RSSI min. Minimum RSSI value of the transponder. Calculated over all successful inven-
RSSI max. Maximum RSSI value of the transponder. Calculated over all successful inven-
