Blocks S5-115F Manual
FB 10 STL Explanation
NETWORK 1 0000
NAME :REGLER 1
0005 :L FW 0 LPLZ-SEQUENCE
0006 :L KF +1
0008 :+F
0009 :T FW 0
000A :
000B :C DB 30 OPEN CONTROLLER DB
000C :
000D : ***********************************
000E : READ IN CONTROL BITS FOR CONTROLLER
000F : ***********************************
0010 :
0011 :L PY 0 READ IN CONTROL INPUTS
0012 :T FY 10 FOR CONTROLLER
0013 :T DR 11 AND STORE IN DR 11
0014 : CAUTION:
0015 : IMPORTANT CONTROL INFORMATION
0016 : FOR OB 251 IS STORED IN DL 11.
0017 : FOR THIS REASON THE CONTROL BITS
0018 : MUST BE TRANSFERRED WITH DR 11
0019 : IN ORDER NOT TO
001A : INFLUENCE DL 11.
001B :
001C : ***********************************
001D : READ IN ACTUAL VALUE AND SETPOINT
001E : ***********************************
001F :
0020 :A F 12.0 ZERO FLAG
0021 :R F 12.0 (FOR UNUSED FUNCTIONS IN FB 250)
0022 :AN F 12.1 1 FLAG
0023 :S F 12.1
0024 :
0025 :JU FB 250 READ IN ACTUAL VALUE
0026 NAME :AGF:ANEI
0027 BG : KF +128 MODULE ADDRESS
0028 KN : KF +0 CHANNEL NUMBER
0029 OGR : KF +2047 UPPER LIMIT ACTUAL VALUE
002A UGR : KF -2047 LOWER LIMIT ACTUAL VALUE
002B DRAK : F 12.0 NO WIRE-BREAK DETECTION
002C ODGR : KF +0 IRRELEVANT SINCE NO DRAK
002D UDGR : KF +0 IRRELEVANT SINCE NO DRAK
002E PASS : KF +0 PASSIVATION VALUE
002F EINZ : F 12.0 NO SELECTIVE SAMPLING
0030 DIR : F 12.1 READ IN VIA DIRECT ACCESS
0031 XA : DW 22 STORE SCALED ACTUAL VALUE IN CONTROL DB
0032 FB : F 12.2 ERROR BIT
0033 BU : F 12.3 OVERRANGE
0034 TBIT : F 12.4 ACTIVITY BIT
0035 TKON : F 12.5 TEST CONFLICT
0036 :
0037 :
0038 :JU FB 250 READ IN SETPOINT
