S5-115F Manual Blocks
FB 10 (Continued) STL Explanation
0039 NAME :AGF:ANEI
003A BG : KF +128 MODULE ADDRESS
003B KN : KF +1 CHANNEL NUMBER
003C OGR : KF +2047 UPPER LIMIT SETPOINT
003D UGR : KF -2047 LOWER LIMIT SETPOINT
003E DRAK : F 12.0 NO WIRE-BREAK DETECTION
003F ODGR : KF +0 IRRELEVANT
0040 UDGR : KF +0 IRRELEVANT
0041 PASS : KF +0 PASSIVATION VALUE
0042 EINZ : F 12.0 NO SELECTIVE SAMPLING
0043 DIR : F 12.1 READ IN VIA DIRECT ACCESS
0044 XA : DW 9 STORE SCALED SETPOINT IN CONTROL DB
0045 FB : F 13.1 ERROR BIT
0046 BU : F 13.2 OVERRANGE
0047 TBIT : F 13.3 ACTIVITY BIT
0048 TKON : F 13.4 TEST CONFLICT
0049 :
004A :A F 10.0 IN MANUAL MODE, THE
004B :JC =WEIT SETPOINT IS SET TO EQUAL
004C :L DW 22 THE ACTUAL VALUE SO THAT
004D :T DW 9 THE CONTROLLER WILL RESPOND
004E : TO ANY CONTROL DEVIATION
004F : WITH A P JUMP WHEN
0050 : SWITCHING TO
0051 : AUTOMATIC MODE
0052 WEIT :
0053 : ********************************
0054 :JU OB 251 CALL CONTROLLER
0055 : ********************************
0056 :
0057 : ********************************
0058 : OUTPUT MANIPULATED VARIABLE Y
0059 : ********************************
005A :JU FB 251
005B NAME :AGF:ANAU
005C XE : DW 48 MANIPULATED VARIABLE Y TO ANALOG OUTPUT
005D BG : KF +176 MODULE ADDRESS
005E KNKT : KY 0,1 CHANNEL 0, FIXED-POINT BIPOLAR
005F OGR : KF +2047 UPPER LIMIT OF CORRECTING SIGNAL
0060 UGR : KF -2047 LOWER LIMIT OF CORRECTING SIGNAL
0061 FEH : F 13.5 ERROR BIT FOR LIMIT SPECIFICATION
0062 BU : F 13.6 OVERRANGE
0063 :BE
