Configuring with COM 115F S5-115F Manual
Press keys F1 to F7 to execute the following functions:
F1 Print all DIs
All digital inputs are printed as type matrices corresponding to the I/O configuration
DB 1.
F2 Print all DQs
All digital inputs are printed as type matrices corresponding to the I/O configuration
DB 1.
F3 Print all AIs
All analog inputs are printed as type matrices corresponding to I/O configuration DB 1.
F4 Print all AQs
All analog outputs are printed as type matrices corresponding to I/O configuration DB
1.
F5 Print all configuration DBs
The entire configuration is printed out.
F6 Printing out a specific I/O type. All inputs/outputs of this type are printed out using this
function. You will be prompted for the type number after pressing the F6 key. This is
checked for accuracy after pressing <CR>. Wrong type numbers are rejected with the
error message
”WRONG TYPE”.
If the type is not available, the following message appears:
”DB(S) NOT AVAILABLE”.
The function is aborted with the <Break> key.
F7 Print DB1
Using this function, you can print DB1 out together with information about the opera-
ting system, communications and mailbox table. The parameters are grouped according
to function in the printout.
F5 Select program file
After pressing the F5 key in the System Handling menu, you can select a program file. If you
access the hard disk or floppy before defining the program file, the ”B:@@@@@@ST.S5D”
file will be accessed.
After selecting the program file, you can access the Delete, Configure, Transfer, Print etc.
functions as often as you like on the floppy data blocks.
F7 Auxiliary functions
This key calls the STEP 5 auxiliary functions. For more detailed information, please see your
programmer manual.
1-28
EWA 4NEB 811 6149-02
