S5-115F Manual Configuring with COM 115F
If only <CR> is pressed in answer to any of the following prompts
”COPY (W)ORD/(B)YTE?”,
” WORD(S)/BYTE(S) TO COPY”,
”DEST. NO(S)”,
the copy routine will be aborted and you will be returned to type entry.
In order to avoid erroneous copy commands, the ”COPY?” message is displayed after com-
pletion of the last initialization. Press the <Exec> key to start, or press the <Break> key to
abort, the Copy function. The program returns to the initial state for entering the type
number.
F3 Swap
The parameters required for this function must be generated in the same way as those for
the Copy function. The syntax for assigning the parameters is described in the same chapter.
Byte-wise and bit-wise swapping is not possible.
The swap procedure is the same as the copy procedure. The prompts are as follows:
”SWAP WORD(S)
AND WORD(S)”
After the parameters have been set, the SWAP prompt appears. You can initiate the
procedure by pressing the <Exec> key or you can abort the function with the <Break> key,
and return to the initial state for type entry.
F4 Delete
This function enables the user to delete one or more successive bytes. Every input, which is
checked internally for validity, is confirmed with <CR>. Any discrepancies are displayed in
the status line with an error message.
The following prompt appears in the case of digital modules:
”DELETE (W)ORD/(B)YTE?”:
This prompt does not appear in the case of analog modules since only words can be deleted
here. When deleting words, enter a single number or the block start and block end,
separated by a hyphen, in answer to the ”DELETE WORD(S):” prompt. The block start must
be less than the block end.
The numbers of words may only be even numbers from 0 to 254!
EWA 4NEB 811 6149-02
1-35
