System Specifications
A-2
TI545/TI555 System Manual
A.1 Series 505 System Specifications
T
able A-1
Environmental
Specifications
Models
PPX:545–1102 Controller
PPX:555–1101 Controller
PPX:555–1102 Controller
PPX:505–6851 Remote Base Controller
PPX:505–6660A Power Supply
PPX:505–6663 Power Supply
Storage Temperature
–40° to 70°
C; –40
°
to 158
°F
Operating Temperature
0° to 60°
C; 32
°
to 140
°F
Relative Humidity 5% to 95% noncondensing
Vibration
Sinusoidal:
Random:
IEC 68-2-6, Test Fc;
0.15 mm peak-to-peak, 10–57 Hz;
1.0 g, 57–150 Hz
NAVMA
T P–9492 or IEC 68–2–34,
Test Fdc with 0.04 g
2
/Hz,
80–350 Hz, and
3 dB/octave rolloff, 80–20 Hz and
350–2000 Hz at 10 min/axis
Impact Shock
IEC, 68–2–27, T
est Ea; Half sine, 15 g 11 ms
Pollution Degree
2, IEC664, 684A
Electric Noise Immunity
Conducted noise:
Radiated noise:
Electrostatic discharge:
IEC 801, Part 4, Level 3
MIL-STD-461B, Part 4; CS01, CS02, CS06
IEC 255–4, Appendix C
EEC 4517/79 Com(78) 766 Final, Part 4
IEEE 472, 2.5 kV
IEC 801 Part 3, Level 3
MIL-STD-461B, Part 4; RS01, RS02
IEC 801, Part 2, Level 4 (15 kV)
System Isolation
1500 V
rms (user-side to controller-side)
