3-18
Installing Series 505 System Hardware TI545/TI555 System Manual
Installing Series 505 Remote Base Controller (continued)
The
RBC has a jumper to select the output state during a communication
loss (Figure 3-14). If the output modules in the remote base have a selection
switch, the freeze selection will override the output module’
s selection.
Outputs
of
f
(default)
Freeze
OFF FRZ
OFF FRZ
Figure 3-14 Series
505 RBC Jumper Locations
