3-3
TI545/TI555 System Manual
Installing Series 505 System Hardware
3.2 Series 505 Bases
The
controller is housed in a Series 505 base assembly
. A base assembly has
slots for the programmable controller or remote base controller (RBC),
power supply
, and the I/O modules. Four base assembly models are
currently available (see T
able 3-1).
T
able 3-1
Base Assembly Models
Model Number of Slots Mounting
PPX:505–6504 4 NEMA panel
PPX:505–6508 8 NEMA panel
PPX:505–6511 11 NEMA panel or rack
PPX:505–6516 16 NEMA panel or rack
Series
500 bases can be connected to a TI545/TI555 PLC system as a remote
I/O base assembly
. The TI545/TI555 controller is capable of addressing the
Series 500 base assembly through the RBC (PPX:500–51
14–A). See
Appendix D for information about upgrading Series 500 bases.
Using the PPX:505–6860 RS-485/RF Converter the TI545/TI555 controller
can connect to the TI545/TI555 Bases in an RF I/O Channel using the
PPX:500–21
14A or the TI505–6850–A RBCs. Refer to the
SIMATIC TI505
Redundant I/O Systems User Manual
, PPX:505–8125–x for additional
information.
Description
Connecting Series
500 Bases
