Siemens SIMATIC TI555 User Manual

3-17
TI545/TI555 System Manual
Installing Series 505 System Hardware
The factory dipswitch, labeled SW 3 on the board is for factory use only . Do
not change the settings on this dipswitch. If the dipswitch setting is
accidentally changed, or you are installing a new RBC, refer to T able 3-5 for
the proper dipswitch settings.
T able 3-5 Series 505 RBC SW 3 (Factory) Dipswitch Setting
Dipswitch
1 2 3 4
On Off Off Off
Y ou can select the state you want the outputs, controlled by the RBC, to be
set to whenever a communication error occurs. Previous models of the RBC
automatically set all outputs to off (0) when communication is lost. The A
version of RBCs allow you to either freeze the outputs in the state they were
in when communication was lost, or have the outputs set to off (0).
Energized parts could fail in an unsafe condition.
If the RBC fails or the system loses power , the outputs will go off (0)
regardless of the jumper selection.
This could cause damage to equipment or death or injury to
personnel.
Series 505 RBC
SW 3 (Factory)
Dipswitch Settings
Output State
Selection
WARNING
!
