1-5
System Overview
TI545/TI555 System Manual
The TI545/TI555 controller system uses individual Series 505 or Series 500
I/O modules for I/O interfaces. A full line of discrete, analog, word, and
intelligent I/O modules are available for handling almost any input or
output specification. These I/O modules are rugged, plug-in devices capable
of functioning in harsh environments within the operating specifications.
The controllers can also communicate with other devices through the
SINECr H1 or SIMA TICr TIWAY

Local Area Networks. See documents
listed in the Preface of this manual for information on these systems.
P/S
P/S
Local I/O up to
16 I/O Slots
Remote I/O up
to 15 additional
bases.
Series 505 and
Series 500 I/O
can be used.
P/S
RBC
500–
5114
*The 8-slot and 16-slot I/O bases operate with the PPX:500–5840 Adapter .
Series 505
I/O 4, 8, and
16 Slots
TISOFT
Programming Unit
CVU100 CVU1000/10000
Series 500
6, 8*, 12, 14, &
16* I/O slots
N
I
M
RBC
PPX:
505–
6851
CPU
PPX:
Series 505 I/O
4, 8, and 16
Slots
CP
TF
1434
TIWAY
SINEC H1
SIMATIC PCS
Figure 1-2 TI545/TI555 System Using Series 500 and Series 505
Components
