Technical information
7.8 Technical specifications of the IFPs
IFP V2, IFP V2 PRO, IFP V2 ETH
Operating Instructions, 03/2023, A5E46641410-AE
125
Weight of the PRO devices for support arm (not extendable, flange top) and for pedestal
(extendable, flange bottom)
Support arm/pedestal devices
12" PRO
15" PRO
19" PRO
22" PRO
24" PRO
Weight without packaging, with
strain relief plate
4.0 kg
5.3 kg
6.3 kg
7.6 kg
9.2 kg
Weight of the PRO devices for support arm (extendable, round tube)
Round tube devices 12" PRO 15" PRO 19" PRO 22" PRO 24" PRO 24" PRO
Portrait
Weight without packaging, with
strain relief plate
4.4 kg 5.9 kg 6.9 kg 8.2 kg 9.9 kg 9.2 kg
Display
IFP V2 devices
12" devices
15" devices
19" devices
22" devices
24" devices
Type
LCD widescreen TFT
Active display diagonal
12.1"
15.6''
18.5''
21.5''
23.8''
Active display area
261 x 163
mm
344.2 x 193.5
mm
409.8 x 230.4
mm
475.2 x 267.3
mm
527.0 x 296.5
mm
Resolution 1280 × 800
pixels
1920 × 1080
pixels
1920 × 1080
pixels
1920 × 1080 p
ixels
1920 × 1080 pi
xels
Possible colors
Up to 16 million
Brightness (typical value)
400 cd/m²
400 cd/m²
350 cd/m²
250 cd/m²
250 cd/m²
Contrast Ratio
800:1
700:1
1000:1
1000:1
1000:1
Brightness control
Yes, using PDT software
Backlight
LED
LED
Half Brightness Life Time (MTBF
1
)
50000 h
30000 h
Pixel error class in accordance with
ISO 9241-307
II
1
MTBF: Operating hours after which the maximum screen brightness is reduced by half compared to the original value.
MTBF is increased by using the integrated dimming function, for example time-controlled via screen saver or centrally
via PROFIenergy.
Input device
IFP V2 devices
12"
15"
19"
22"
24"
Touch screen
Yes, projective capacitive
Interfaces
IFP V2 devices
Standard versions
Extended versions and PRO devices
Ethernet Monitors
DVI-D
Yes
No
DisplayPort
Yes, DisplayPort V1.2
Yes, DisplayPort V1.1
