Installing and connecting the device
3.4 Mounting the Transceiver Unit
IFP V2, IFP V2 PRO, IFP V2 ETH
54 Operating Instructions, 03/2023, A5E46641410-AE
Alternatively, you can mount the unit on a pedestal. Follow the instructions for pedestal
mounting (Page 48) and use the round tube plug, see section "System components for PRO
devices (Page 20)".
3.4 Mounting the Transceiver Unit
notes for installation
The device is approved for operation in closed rooms only.
For installation in a cabinet, observe the manual "Installing control systems interference-
proof (https://support.industry.siemens.com/cs/ww/en/view/59193566)" as well as the
relevant DIN/VDE provisions and the applicable country-specific regulations.
Requirement
• The mounting rail is fastened to the side or rear of the Transceiver Unit according to the
desired mounting position.
Mounting onto standard rail
The following procedure describes an example of mounting a Transceiver Unit with a
mounting rail attached at the side on a standard mounting rail. The mounting of a
Transceiver Unit with a mounting rail attached at the rear is carried out in the same way.
