Siemens SIMATIC V2 - PRO Devices for Support Arm (Extendable, Round Tube)

Overview
1.4 Design of the PRO devices
IFP V2, IFP V2 PRO, IFP V2 ETH
Operating Instructions, 03/2023, A5E46641410-AE
15
Bottom view
①
Mechanical interface for fastening
Rear view
①
Backplane cover
②
Enclosure
③
Rating plate
④
Mechanical interface for fastening
1.4.3 PRO devices for support arm (extendable, round tube)
This section describes the structure of the PRO devices for support arm (extendable, round
tube) using the example of the IFP1500 PRO for support arm (extendable, round tube).
