Preface
IFP V2, IFP V2 PRO, IFP V2 ETH
4 Operating Instructions, 03/2023, A5E46641410-AE
• The standard versions, extended versions and Ethernet Monitors are referred to as "built-in
devices".
• The devices IFP1200 V2 PRO, IFP1500 V2 PRO, IFP1900 V2 PRO, IFP2200 V2 PRO and
IFP2400 V2 PRO are referred to as "PRO devices".
• The projective-capacitive multi-touch screen of the devices is also referred to as "capacitive
multi-touch screen" or "touch screen".
The following applies to the possible operating modes of an IFP:
• In "standard mode", an IFP is directly connected to the PC via a USB cable and a
DVI/DisplayPort cable ≤ 5 m long.
• In "Extended mode", an extended version or a PRO device can be connected via a Cat. 6A
Ethernet cable > 5 m and the Transceiver Unit connected to the PC.
• In "Commissioning" mode, an Ethernet Monitor is prepared for "Ethernet" mode. In
"Ethernet" mode, the PC and Ethernet Monitor are connected with an Ethernet cable
which transfers all signals for operator control and monitoring.
Figures
This manual contains figures of the described devices. The supplied device might differ in
some details from the figures. Within some of the figures, one device is used to represent
several devices.
Picture components are marked with black position numbers on a white background ①, ②,
③, ...
Steps in the figures are identified with white process numbers on a black background
according to the sequence in which they have to be executed:
, , , ...
History
The following released versions of these operating instructions have been published to date:
08/2020 Description of the following devices added:
• Built-in devices IFP1200 V2, IFP1200 V2 extended
• Built-in devices IFP1500 V2 ETH, IFP1900 V2 ETH, IFP2200 V2 ETH, IFP2400 V2 ETH
• PRO devices IFP1200 V2 PRO and IFP2400 V2 PRO
Description of approvals CE, UL, FM, and ATEX/IECEx updated, CCC added
Description of approvals UKCA added and UKEX added.
Description of approvals UL Hazardous updated.
