09.95 2 PLC Machine Data
2.1 PLC machine data for operating system (DB 60)
2 PLC Machine Data
2.1 PLC machine data for operating system (DB 60)
MD
No.
D e s i g n a t i o n
Standard
mach. data
Maximum
input value
Input
resolution
DB60
DW
22Call time reference for OB 5 1 1 to 3 2.5 ms
33Call time reference for OB 6 1 1 to 9 10 ms
44Call time reference for OB 7 1 1 to 255 100 ms
55Last step 5 timer 64 255
1)
88Last active channel 1 4
1)
99Last active spindle 1 6
1)
10 10 Last active axis 2 for T
3 for M
15
11 11 Delete threshold inputs 127 64 ... 127
12 12 Delete threshold outputs 127 64 ... 127
13 13 Reserved
14 14 Reserved
17 17 Number of wait cycles with
occupied UI
110
18 18 No. of UIs on synchronization 0 31
19 19 No. of function numbers 3 10
20 20 Function number for core
sequence triggering
25 255
21 21 Function number for core
sequence triggering
26 255
22 22 Function number for core
sequence triggering
30 255
23 23 Function number for core
sequence triggering
0 255
24 24 Function number for core
sequence triggering
0 255
25 25 Function number for core
sequence triggering
0 255
26 26 Function number for core
sequence triggering
0 255
27 27 Function number for core
sequence triggering
0 255
_______
CL = Computer link
1)
SW 1 and 2 only
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 2–1
