Siemens SIMODRIVE 611-D Installation Guide

1 NC/Drive Machine Data 09.95
1.6.1 Spindle-specific bits, standard assignments
1.6.1 Spindle-specific bits, standard assignments
M version T version
MD No. 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
5200 0 0 0 1 0 1 0 0 0 0 0 1 0 1 0 0
5201 0 0 0 1 0 0 0 0 0 0 0 1 0 0 0 0
5202 0 0 0 1 0 0 0 0 0 0 0 1 0 0 0 0
5203 0 0 0 1 0 0 0 0 0 0 0 1 0 0 0 0
5204 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5205 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5210 1 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0
5211
to
5215
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5220
to
5225
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5230
to
5235
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5240
to
5245
0 0 0 0 0 1 0 0
:
0 0 0 0 0 1 0 0
0 0 0 0 0 1 0 0
:
0 0 0 0 0 1 0 0
5250
to
5255
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5260
to
5265
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5270
to
5275
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5280
to
5285
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5290
to
5295
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5300
to
5305
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
1–28 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
