1 NC/Drive Machine Data 07.97
1.10.1 Spindle-specific MD
1.10.1 Spindle-specific MD
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
2400*
:
2407*
1st para. set
Number of teeth motor
1)
:
8th para. set
1
999999
99 999 999
2)
--
2408*
:
2415*
1st para. set
Number of teeth spindle
1) :
8th para. set
1
999999
99 999 999
2)
--
2416*
:
2419*
Zero mark 1th para. set
correction+
1) :
4th para. set
0
999999
16 000
2)
MS units
2420** r1: Load no. of revolutions 1
2421** r2: Motor no. of revolutions 1
2422** p: Pulses per revolution 1024
2430*
:
2433*
Zero mark 5th para. set
correction+
1) :
8th para. set
0 999999 MS units
2434*
:
2441*
Zero mark 1st para. set
correction -
1) :
8th para. set
0
999999
16 000
2)
MS units
2442*
:
2448*
Feedforward control factor,
2nd to 8th para. set
1)
0 1000 -- 0.1 %
2449*
:
2456*
1st para. set
D comp. feedf. contr.
1) :
8th para. set
0 1000 -- 0.1 %
2457*
:
2463*
Time constant, symmetr. filter
2nd to 8th para. set
1)
0
9999
1 000
2)
-- 0.1 ms
_______
1) SW 4 and higher
2) SW 4.4 and higher
1–44 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
