1 NC/Drive Machine Data 09.95
1.1 General values
1.1 General values
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
1 Speed after prelimit switch 500 100000 IS 1000 units/min
2
3 Corner deceleration rate 500 100000 IS 1000 units/min
6 Threshold for point of intersect.
switch
1000 16000
2000
*)
IS units
7 Circle end point monitoring 5 32000 IS units
9 Error window on reapproach to
circle contour
200 32000 IS units
10 Feed after block search 1000 100000 IS 1000 units/min
13 Number of TO parameters 10 32 --
14 First password protected R
parameter
0 999
1299
*)
--
15 Last password protected R
parameter
0 999
1299
*)
--
16 First keyswitch protected R
parameter
0 999
1299
*)
--
17 Last keyswitch protected R
parameter
0 999
1299
*)
--
18 Zero offset group (L960) 1 10 --
20 Basic angle for nutating head 0 180000 IS 10
-3
degrees
23 Number of buffer pairs
CP 231
16 16 --
--
24 Number of buffer pairs
CP 315 - 1
16 16 -- --
25 Number of buffer pairs
CP 315 - 2
16 16 --
--
26 User program useful data
length CP 231
234 254
*)
-- characters
27 User program useful data
length CP 315 - 11 - 16
234 254
*)
--
characters
28 User program useful data
length CP 315 - 2
234 254
*)
--
characters
_______
*) SW 4 and higher
1–2 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
