1 NC/Drive Machine Data 06.93
1.8.1 Axis-specific MD bits 1, standard assignments
1.8.1 Axis-specific MD bits 1, standard assignments
M version T version
MD No. 76543210 76543210
5600 00100000 00100000
5601 00100000 00100000
5602 00100000 00100000
5603 00100000 00100000
5604
to
5629
00100000
:
00100000
00100000
:
00100000
5640 10000000 10000000
5641 10000000 10000000
5642 10000000 00000000
5643
to
5669
00000000
:
00000000
00000000
:
00000000
5680 00000000 00000000
5681 00000001 00000010
5682 00000010 00000000
5683
to
5709
00000000
:
00000000
00000000
:
00000000
5720 00000000 00001010
5721
to
5749
00000000
:
00000000
00000000
:
00000000
5760
to
5789
00000000
:
00000000
00000000
:
00000000
5800
to
5829
00000000
:
00000000
00000000
:
00000000
5840
to
5869
00000000
:
00000000
00000000
:
00000000
1–32 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
