1 NC/Drive Machine Data 12.93

1.9 Compensation points for leadscrew error compensation

7 6 5 4 3 2 1 0

Bit No.

MD No.

6000

yes/no +/– yes/no +/– yes/no +/– yes/no +/–

6001

yes/no +/– yes/no +/– yes/no +/– yes/no +/–

6002

yes/no +/– yes/no +/– yes/no +/– yes/no +/–

- // -

6248

yes/no +/– yes/no +/– yes/no +/– yes/no +/–

6249

yes/no +/– yes/no +/– yes/no +/– yes/no +/–

C point 4 C point 3 C point 2 C point 1

C point 8 C point 7 C point 6 C point 5

C point 12 C point 11 C point 10 C point 9

C point 996 C point 995 C point 994 C point 993

C point 1000 C point 999 C point 998 C point 997

– bit = 0 negative compensation

+ bit = 1 positive compensation

no bit = 0 no compensation

yes bit = 1 compensation

1–34
